Jaxon Steel is a reliable producer and supplier of superior metal products in Manila, Philippines. With expertise in Alloy Steel Grade 5 Foil, we supply to various industries such as aerospace, automotive, and manufacturing. Our precision-crafted foils possess superior strength, corrosion resistance, and durability, making them suitable for extreme applications. Jaxon Steel prioritizes quality and customer satisfaction with its commitment to delivering superior materials, competitive pricing, and prompt delivery. Whether industrial or for commercial purposes, our Alloy Steel Grade 5 Foil comes with the topmost reliability and performance standards. Get in touch with us for high-quality steel solutions.
Alloy Steel Grade 5 Foil consists of chromium (0.50-0.80%), molybdenum (0.25-0.40%), manganese (0.70-1.00%), carbon (0.28-0.33%), phosphorus (≤0.035%), sulfur (≤0.040%), and silicon (0.15-0.35%). This alloy has high tensile strength (up to 850 MPa), superior hardness (Rockwell C30-35), and high yield strength (approximately 680 MPa).It exhibits good resistance to wear, toughness, and durability, thus making it a good fit for aerospace, automotive, and industrial applications. Its high machinability and resistance to heat deliver reliable performance under extreme conditions beyond industry expectations of strength and resistance to corrosion.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 5 | 0.15 max | 0.30-0.60 | 0.5 max | 0.035 max | 0.030 max | 4.0 – 6.0 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Alloy Steel Grade 5 Foil has extensive uses in the aerospace, automobile, manufacturing, and defense industries due to its high strength, corrosion resistance, and durability. The foil has widespread use in precision components, heat exchangers, turbine blades, and engine parts where high performance is required under rigorous conditions. The foil also finds applications in electrical shielding, industrial gaskets, and high-temperature applications on account of its good thermal stability. Moreover, it is well-suited for wear-resistant coatings, structural reinforcement, and tooling. Its machinability and toughness make it a choice material for challenging engineering applications demanding reliable, long-life materials.
