Manila, Philippines-based Liam Steel is a reliable supplier of Carbon Steel ASME SA 179 Tubing. Providing best-in-class solutions to suit several industry standards. We provide high-quality products of Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel, thus ensuring durability as well as improved performance. The commitment to perfection is evident from our rigorous quality checks and fast supply chain. Our emphasis on reliability means that we packed our products safely and deliver them in good time to satisfy customers.
Carbon Steel ASME SA 179 Tubing is a low-carbon seamless tube used mainly in heat exchangers and condensers. It is composed of carbon (≤0.06%), manganese (0.27-0.63%), phosphorus (≤0.035%), and sulfur (≤0.035%). Providing outstanding thermal conductivity and corrosion resistance. This tubing is cold-drawn for improved dimensional tolerance, smooth inner surfaces and excellent strength. Its fine grain texture guarantees durability and effective heat transmission, thus rendering it a desirable option for those applications where high-performance and accurate fluid or gas flow control is necessary.
| Product | ASTM A179 Seamless Steel Tubes |
| Specification | ASTM A179 / ASME SA179 |
| Standard | ASTM A179/A179M, ASME SA179/SA179M is the standard applicable to Seamless cold drawn low carbon steel heat exchanger and condenser tubes |
| Size OD (In mm) | 3/4” (19.05mm), 1” (25.4mm), 1¼” (31.75mm), 1½” (38.1mm), 2” (50.8mm), 2½” (63.5mm), 3” (76.2mm) |
| Wall Thickness (BWG, mm) | 16BWG (1.651mm), 14BWG(2.108mm), 12BWG(2.769mm), 10BWG(3.404mm), 8BWG(4.191mm) |
| Application | For high, middle, low pressure boiler and pressure purposes |
| Length | 5800mm; 6000mm; 6096mm; 7315mm; 11800mm; and so on. Max length: 27000mm, also U bending can be offered |
| Product Marking | ASTM A179 or ASME SA179, size, heat no., Lot No. and Manufacture name or logo. |
| Other Testing | Hydrostatic Test |
| Type | Seamless – Hot Rolled / Cold Drawn |
| Form | Round |
| International Standards | ASME, API, EN, DIN, ISO |
| End | Plain End, Beveled End, Coupling |
| Inspection | Third Party Inspection, Buyer Inspection |
| Packing | Weaving Bag, Seaworthy Bundles, Wooden Case if required |
| Specials | Sizes and Specification other than above can be manufactured on request |
| Certification | EN 10204 3.1 |
| Chemical Composition | ||||
| C | Mn | P≤ | S≤ | Si≤ |
| 0.06-0.18 | 0.27-0.63 | 0.035 | 0.035 | 0.25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel ASME SA 179 Tubing in Manila, Philippines. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to reliable delivery and exceptional customer service, Jaxon Steel provides top-grade materials that ensure superior performance in various industrial applications. Trust us for all your Carbon Steel ASME SA 179 Tubing needs.
| Tensile | Yield | Elongation | Hardness |
| Strength (Mpa) | Strength (Mpa) | (%) | (HRB) |
| ≥325 | ≥180 | ≥35 | ≤72 |
ASME SA 179 Carbon Steel Tubing is used extensively in heat exchangers, boilers, condensers and superheaters because of its superior thermal conductance and corrosion resistance. Its accurate size and smooth internal bore render it apt for effective heat transmission applications. The main users of this tubing are power plants, chemical processing, refineries, and HVAC systems. This tubing is also used in the marine and automotive industries for cooling systems. Due to its toughness and high pressure resistance, this tubing is suited for demanding industrial environments.
Liam Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Manila, Philippines.
