Jaxon Steel is a premier producer and distributor of high-strength S890QL steel sheets and plates in Manila, Philippines. Fuelled by an unrelenting passion for excellence, we deliver durable, high-strength, quenched, and tempered steel solutions for multiple industries such as construction, heavy machinery, and engineering. Our S890QL steel plates are renowned for their superior toughness, weldability, and impact resistance, making them suitable for demanding applications. At Jaxon Steel, we provide precision-cut, dependable, and affordable steel products customized to your project’s specifications with high-quality and quick turnaround.
S890QL plates and sheets are high-strength structural steel, tempered, and quenched with excellent weldability and toughness. They have a composition of material including low carbon (≤0.2%), manganese (≤1.7%), silicon (≤0.8%), chromium (≤1.5%), nickel (≤2.0%), molybdenum (≤0.7%), and boron (≤0.005%) with high strength and durability. Their mechanical properties range from a minimum of 890 MPa yield strength, tensile strength of 940–1100 MPa, and outstanding impact resistance at low temperatures. With excellent toughness and good formability, S890QL steel plates are suitable for heavy-duty use in construction, mining, and engineering sectors.
Steel Standard: EN10025
Thicknesses: 3 mm to 300 mm
Widths: 2000 mm, 2500 mm, 3000 mm
Lengths: Up to 12000 mm long
Delivery State:Quenched and Tempered
Packing: Standard seaworthy package
|
C |
Si |
Mn |
P |
S |
B |
Cr |
Cu |
Mo |
|
0.20 |
0.80 |
1.70 |
0.020 |
0.010 |
0.005 |
1.50 |
0.50 |
0.70 |
|
N |
Nb* |
Ni |
Ti* |
V* |
Zr* |
|||
|
0.015 |
0.06 |
2.0 |
0.05 |
0.12 |
0.15 |
|
mm |
Yield Strength ReH (MPa) |
Tensile Strength Rm (MPa) |
Elongation A5 % minimum |
Impact Strength J, Minimum |
|
3 to 50 |
890 |
940 – 1100 |
11 |
30 @ -40º C |
|
> 50 to 100 |
830 |
880 – 1100 |
11 |
30 @ -40º C |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
S890QL sheet and plate exhibits wide-ranging use in industries that require high strength and durability of the material. Their enhanced mechanical properties make them suitable for building, mining, heavy equipment, road transportation, offshore construction, cranes, and bridges. S890QL structural steel plate is used for fabrication of loaders, bridges, cranes, structural components that require maximum load-carrying capacity. In the power industry, wind towers and pressure vessels find S890QL to be the metal of choice. Its superior toughness and impact resistance also qualify it for defense and armored vehicles. With good weldability and formability, S890QL steel plates improve performance in severe conditions for reliability and safety in harsh industrial applications.
