Liam Steel is one of the leading manufacturers and suppliers of high-quality steel products based in Manila, Philippines. The company is well known for producing the ARCELOR 500 grades of sheets and plates that have been recognized for their high hardness, strength, and wear resistance. This plate endures with regard to various heavy-duty operations in mining, construction, material handling as well as operations related to heavy machinery. The company insists on excellence and makes sure that precision-engineered solutions will improve performance and hence lower the operating costs while prolonging service life.
ARCELOR 500 sheets and plates consist of high-grade alloy steel with optimized content of carbon, manganese, chromium, and boron, providing outstanding hardness and wear resistance. They possess better mechanical properties, such as high tensile strength, impact toughness, and a hardness of around 500 HBW. They have excellent durability, abrasion resistance, and improved weldability. Advantages are longer life, lower maintenance costs, and applicability in harsh applications such as mining, construction, material handling, and heavy equipment to provide maximum performance and efficiency.
Item: ARCELOR 500
Thickness : 5mm to 150mm
Length : 6,000mm to 12,000mm
Width : 1,500mm to 2,500mm
Heat Treatment: N, Q+T
Surface Point : EP, PE, HDP, SMP, PVDF
| Plate Thickness MM | %C Max | %Mn Max | %P Max | %S Max | %SI Max | %Cr Max | %Ni Max | %Mo Max | B Max | CE Max | PCM Max |
| 6.0 – 20.0 | 0.60 | 0.41 | |||||||||
| 21.0 – 40.0 | 0.30 | 1.60 | 0.025 | 0.010 | 0.70 | 1.50 | 1.50 | 0.70 | 0.040 | 0.65 | 0.43 |
| 41.0 – 50.0 | 0.74 | 0.48 |
| Â | Hardness HBW | Typical yield strength MPa, |
| mm | (min – max 1) | not guaranteed |
| 4 – 32 | 470 – 530 | 1250 |
| (32) – 103 | 450 – 540 | 1250 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| 1/8″ | 3/8″ | 3/4″ | 1-1/2″ | 3″ |
| 3/16″ | 1/2″ | 1″ | 2″ | 4″ |
| 1/4″ | 5/8″ | 1-1/4″ | 2-1/2″ | Â |
| *1/8″ thick plate is available in one size only 60″x 120″. The 3/6″ thick plate is available only as 48″ x 144″ and 96″ x 144″. | ||||
| Thickness | Width | Length |
| 4 | 2000 | 6000 |
| 5 | 2000 | 6000 |
| 6 | 2000 | 6000 |
| 6 | 2500 | 6000 |
| 8 | 2000 | 6000 |
| 8 | 2500 | 6000 |
| 10 | 2000 | 6000 |
| 12 | 2000 | 6000 |
| 15 | 2000 | 6000 |
| 16 | 2000 | 6000 |
| 20 | 2000 | 6000 |
| 25 | 2000 | 6000 |
| 32 | 2000 | 6000 |
| 40 | 2000 | 6000 |
| 50 | 2000 | 6000 |
| 60 | 1800 | 3400 |
