Liam Steel stands out as a top-notch manufacturer and supplier of **ABS AH36 Shipbuilding Steel Sheets and Plates** right here in **Manila, Philippines**. We’re dedicated to providing high-quality steel solutions tailored for the marine and shipbuilding industries. Our ABS AH36 Sheets and Plates are designed to deliver outstanding strength, toughness, and resistance to corrosion, making them perfect for building vessels that need to endure the toughest marine conditions. Crafted with cutting-edge steelmaking techniques and rigorous quality control, these plates guarantee consistent mechanical performance and a long lifespan. Liam Steel proudly supplies ABS AH36 Shipbuilding Steel to shipbuilders, offshore industries, and various maritime applications throughout the Philippines, offering durable and dependable steel products that adhere to international standards.
Our ABS AH36 Shipbuilding Steel Sheets and Plates are made from **low-alloy, high-strength steel** that includes **carbon, manganese, silicon, nickel, chromium, and molybdenum**. This unique composition ensures exceptional toughness and corrosion resistance. With **tensile strength ranging from 490–620 MPa** and **yield strength around 355 MPa**, these plates promise structural integrity and durability. They also boast excellent weldability, formability, and impact resistance, making them ideal for heavy-duty marine applications that demand reliability in harsh environments.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: AH 36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| C | Si | Mn | P | S | Cr | Mo | Ni | Cu | Cb | V |
| 0.18 | 0.10/0.50 | 0.90/1.60 | 0.035 | 0.035 | 0.20 | 0.08 | 0.40 | 0.35 | 0.02/0.05 | 0.05/0.10 |
| Grade | Re | Rm | Elongation | |
| A50mm | A200mm | |||
| MPan | MPa | % | % | |
| AH36 | 355 | 490/620 | 22 | 19 |
| DNV | GL | LR | BV | CCS | NK | KR | RINA |
| NV A36 | GL A36 | LR A36 | BV AH36 | CCS A36 | KA36 | RA 36 | RINA AH36 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Liam Steel is one of the most prominent manufacturers and suppliers of superior quality ABS AH36 Shipbuilding Steel Sheet and Plates in Manila, Philippines. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| Grade A | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
Liam Steel’s ABS AH36 Shipbuilding Steel Sheets and Plates are extensively utilized in **shipbuilding, offshore platforms, marine structures, and naval applications**. They’re perfect for **hulls, decks, bulkheads, structural framing, and components for offshore construction**, where strength, toughness, and corrosion resistance are essential. These plates ensure reliable performance in **extreme marine conditions, heavy-duty fabrication, and structural applications**, providing safety, durability, and longevity. With Liam Steel’s ABS AH36 Shipbuilding Steel Sheets and Plates, you get high-quality, cost-effective solutions for the maritime and offshore industries, supporting long-term operational efficiency and stability.
