Liam Steel stands out as a top manufacturer and supplier of **ABS DH36 Shipbuilding Steel Sheets and Plates** right here in **Manila, Philippines**. We’re all about providing high-quality, durable steel solutions tailored for the maritime and shipbuilding sectors. Our ABS DH36 Sheets and Plates are crafted to offer outstanding strength, toughness, and resistance to corrosion, making them perfect for vessels and offshore structures that face tough marine conditions. Thanks to our advanced steelmaking techniques, heat treatment, and rigorous quality control, these plates ensure consistent mechanical performance and a long lifespan. We proudly supply ABS DH36 Shipbuilding Steel Sheets and Plates to shipbuilders, offshore industries, and marine applications throughout the Philippines, guaranteeing reliable and high-performance steel products.
Our ABS DH36 Shipbuilding Steel Sheets and Plates are made from **low-alloy, high-strength steel** that includes **carbon, manganese, silicon, nickel, chromium, and molybdenum**. This combination gives them excellent toughness, strength, and corrosion resistance. They boast a **tensile strength between 490–620 MPa** and a **yield strength around 355 MPa**, ensuring dependable impact resistance, weldability, and dimensional stability. These plates are specifically designed to meet stringent marine standards, ensuring they maintain structural integrity even under heavy loads and extreme environmental conditions.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: DH36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| Grade DH36 | C | Si | Mn | P | S | V | Al | Cr | Cu | Mo | Nb | Ni | Ti |
| 0.180 | 0.1-0.5 | 0.90-1.6 | 0.035 | 0.035 | 0.05-0.10 | 0.015 | 0.200 | 0.350 | 0.080 | 0.02-0.05 | 0.400 | 0.020 |
| Grade | Re | Rm | Elongation | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| DH 36 | 355 | 490/620 | 22 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Liam Steel is one of the most prominent manufacturers and suppliers of superior quality ABS DH36 Shipbuilding Steel Sheet and Plates in Manila, Philippines. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| DH36 | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
Liam Steel’s ABS DH36 Shipbuilding Steel Sheets and Plates are widely utilized in **shipbuilding, offshore platforms, marine structures, and naval applications**. They’re perfect for **hulls, decks, bulkheads, structural framing, and components for offshore construction**, where strength, toughness, and corrosion resistance are essential. These plates deliver reliable performance in **harsh marine environments, heavy-duty fabrication, and structural applications**, ensuring safety, durability, and long-term operational efficiency. With Liam Steel’s ABS DH36 Shipbuilding Steel Sheets and Plates, you get high-quality, cost-effective solutions for the maritime and offshore industries.
