Jaxon Steel is a reliable manufacturer and supplier located in the Philippines, specializing in high-quality steel products for a wide range of industries. With many years of expertise, we offer durable and reliable solutions including carbon steel A334 gr 3 pipes. Our A334 Gr3 pipes are known for their extraordinary power, corrosion resistance high pressure and ability to withstand temperature, making them ideal for oil and gas, power generation and applications in chemical industries. we are committed to distributing top-quality products that are beneficial to meet your specific requirements.
Carbon steel A334 gr 3 Tubing are mainly composed of carbon, manganese, phosphorus, sulfur and silicon, with a specific composition of 0.30-0.60% carbon, 0.40–1.06% manganese and minimum phosphorus and sulfur. It is designed for high temperature and high pressure applications. Mechanical properties include the power of 205 MPa (30 KSI) dividends, stretch power 415 to 585 MPa (60 to 85 KSI) and 35% minimum increase. The material reflects excellent weldability, pharmacy and resistance to corrosion, making it suitable for industries such as oil and gas, electricity and chemical processing.
| Element | A/SA 334 Gr A3 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A334 GR 3 Tubing in Manila, Philippines. We offer premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source top-grade raw materials to ensure superior strength and durability for demanding industrial applications. Contact us today for all your Carbon Steel A334 GR 3 Tubing needs!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
Carbon steel A334 gr3 Tubing are widely used in industries that require high -strength materials and excessive temperature and resistance to pressure. General applications include oil and gas, power generation and chemical processing, where pipes are used in heat exchange, boilers and pressure containers. Excellent mechanical properties make it ideal for systems that work at high pressure and temperature. In addition, the A334 G 3 hose is used in the manufacture of pipelines, capacitors and superhirs, where durability and reliability are needed. Its versatility and height performance make it a favorite option for important industrial applications.
